The RV-8 panel template at the panel's dimensions, 33.29 × 12 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
1,331 panels laid out on these 6 templates
The same panel as the RV-8A. Also written RV8 or RV 8.
6 templates for the RV-8
Van's Aircraft · Standard
Start a panel layout on this template
Van's Aircraft · One Piece Panel
Start a panel layout on this template
Hangar Flying · Custom Modular Instrument Panel
Start a panel layout on this template
Van's Aircraft · Shows panel space limitations
Start a panel layout on this template
Van's Aircraft
Start a panel layout on this template
Van's Aircraft · Full width main panel mod
Start a panel layout on this template
Recent RV-8 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an RV-8 panel
The equipment placed most often across the 1,331 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin International, Inc G5 | 514 | 39% |
| Garmin International, Inc G3X Touch | 436 | 33% |
| Garmin International, Inc GMC 507 | 380 | 29% |
| Dynon Avionics Autopilot Panel | 331 | 25% |
| ACK Technologies ELT | 300 | 23% |
| Dynon Avionics VHF COM | 275 | 21% |
| Dynon Avionics Dynon SkyView HDX 10" | 207 | 16% |
| Garmin International, Inc GMA 245 | 188 | 14% |
Other Van's Aircraft panels
From layout to fabricated panel
Lay out the RV-8 panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
