Van's Aircraft RV-3 instrument panel
The RV-3 panel template at the panel's dimensions, 24 × 10.1 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
106 panels laid out on this template
Also written RV3 or RV 3.
Recent RV-3 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an RV-3 panel
The equipment placed most often across the 106 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Airspeed Indicator 3" | 20 | 19% |
| Falcon Gauge Altimeter 3" | 19 | 18% |
| uAvionix Corporation AV-30 PFD | 18 | 17% |
| Sensa Technologies 7277 | 17 | 16% |
| MGL Avionics (Rainbow Aircraft, Inc) VHF Controller | 15 | 14% |
| Garmin International, Inc G5 | 14 | 13% |
| Garmin International, Inc GTX 335 | 11 | 10% |
| Garmin International, Inc GTR 200 | 11 | 10% |
