Van's Aircraft RV-14 instrument panel
The RV-14 panel template at the panel's dimensions, 40.1 × 11.56 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
710 panels laid out on this template
Also written RV14 or RV 14.
2 templates for the RV-14
40.1 × 11.56 in
40.1 × 11.57 in
Recent RV-14 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an RV-14 panel
The equipment placed most often across the 710 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin International, Inc G5 | 268 | 38% |
| Garmin International, Inc G3X Touch | 267 | 38% |
| ACK Technologies ELT | 196 | 28% |
| Garmin International, Inc GMC 507 | 186 | 26% |
| Garmin International, Inc GMA 245 | 139 | 20% |
| Dynon Avionics Autopilot Panel | 135 | 19% |
| Dynon Avionics VHF COM | 99 | 14% |
| Sensa Technologies 7277 | 93 | 13% |
