Piper Aircraft PA-28 instrument panel
The PA-28 panel template at the panel's dimensions, 42.2 × 17.2 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
755 panels laid out on this template
Also written PA28 or PA 28.
Recent PA-28 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in a PA-28 panel
The equipment placed most often across the 755 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Vertical Speed Indicator | 243 | 32% |
| Falcon Gauge Altimeter 3" | 236 | 31% |
| Falcon Gauge Airspeed Indicator 3" | 233 | 31% |
| Garmin International, Inc G5 | 217 | 29% |
| Garmin International, Inc GFC 500 | 169 | 22% |
| Sensa Technologies 7277 | 132 | 17% |
| Garmin International, Inc G3X Touch | 117 | 15% |
| Mid Continent MD93 Digital Clock | 111 | 15% |
