Mooney M20C M20E M20F instrument panel
The M20C M20E M20F panel template at the panel's dimensions, 39.94 × 13.6 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
184 panels laid out on these 2 templates
2 templates for the M20C M20E M20F
Recent M20C M20E M20F panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an M20C M20E M20F panel
The equipment placed most often across the 184 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Airspeed Indicator 3" | 73 | 40% |
| Falcon Gauge Altimeter 3" | 71 | 39% |
| Falcon Gauge Vertical Speed Indicator | 69 | 38% |
| Garmin International, Inc GFC 500 | 66 | 36% |
| Sensa Technologies 7277 | 61 | 33% |
| Garmin International, Inc G5 | 52 | 28% |
| Garmin International, Inc GI 275 HSI | 36 | 20% |
| Garmin International, Inc GI 275 ADI | 36 | 20% |
