Cessna 170B instrument panel
The 170B panel template at the panel's dimensions, 31 × 8 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
87 panels laid out on this template
2 templates for the 170B
31 × 8 in
37 × 10.13 in
Recent 170B panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in a 170B panel
The equipment placed most often across the 87 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Altimeter 3" | 31 | 36% |
| Falcon Gauge Vertical Speed Indicator | 30 | 34% |
| Garmin International, Inc GI 275 ADI | 30 | 34% |
| Falcon Gauge Airspeed Indicator 3" | 28 | 32% |
| Garmin International, Inc GI 275 EIS | 27 | 31% |
| Garmin International, Inc GI 275 HSI | 23 | 26% |
| Electronics International Inc CGR-30P Engine Analyzer | 17 | 20% |
| Garmin International, Inc GNX 375 | 13 | 15% |
