Avid Aircraft MK-4 instrument panel
The MK-4 panel template at the panel's dimensions, 31.5 × 9.02 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
24 panels laid out on this template
Also written MK4 or MK 4.
Recent MK-4 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an MK-4 panel
The equipment placed most often across the 24 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Vertical Speed Indicator | 11 | 46% |
| Falcon Gauge Airspeed Indicator 3" | 11 | 46% |
| Falcon Gauge Altimeter 3" | 9 | 38% |
| UMA Instruments UMA Tach | 7 | 29% |
| The Ray Allen Company Trim Indicator | 6 | 25% |
| ACK Technologies ELT | 6 | 25% |
| GRT Avionics EIS | 6 | 25% |
| The Ray Allen Company RS2 | 6 | 25% |
From layout to fabricated panel
Lay out the MK-4 panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
