Aerosport Products RV-10 instrument panel
The RV-10 panel template at the panel's dimensions, 41.5 × 20.57 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
127 panels laid out on this template
Also written RV10 or RV 10.
2 templates for the RV-10
41.5 × 20.57 in
42.15 × 20.95 in
Recent RV-10 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an RV-10 panel
The equipment placed most often across the 127 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin International, Inc G3X Touch | 71 | 56% |
| Garmin International, Inc GMC 507 | 58 | 46% |
| Garmin International, Inc G5 | 52 | 41% |
| Garmin International, Inc GMA 245 | 35 | 28% |
| Sensa Technologies 7277 | 32 | 25% |
| Garmin International, Inc GTN 750Xi | 24 | 19% |
| Aero Safety Systems AH501 | 22 | 17% |
| ACK Technologies ELT | 21 | 17% |
From layout to fabricated panel
Lay out the RV-10 panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
